The IAG 550 Short Block is designed for modified EJ25 Subarus that need a stronger short block to support increased cylinder pressures created by additional boost pressure. The IAG 550 short block features IAG Spec H-Beam forged connecting rods. The upgraded connecting rods and race bearings are able to support additional engine load produced by larger turbochargers or increased boost which the OEM STI rods found in the Stock short blocks cannot support reliably. Each IAG 550 Short Block starts with brand new EJ25 Subaru 2.5L, 99.5mm stock bore engine case halves as standard. The case haves are carefully measured and assembled using a new 2017+ Subaru 2.5L nitride treated STI crankshaft, which is matched to ACL or King race main bearings. The IAG 550 Short Block features IAG Spec H-Beam Connecting Rods with ARP2000 rod bolts, along with ACL or King race rod bearings. The case halves are sealed with new OEM main case bolts and sealant. Finally, IAG Spec JE 99.5mm Forged Pistons are carefully selected, measured, and installed to finish off the short block.
Features & Benefits:
- The IAG 550 Short Block has a power output rating of 550 BHP
- All IAG Short Blocks are balanced and blueprinted
Associated Comments:
- 550 Short Block Includes: Case Halves - Brand new Subaru OEM case halves 99.5mm stock bore, Pistons - IAG-Spec JE 99.5mm Forged Pistons, Ring Set, .180" Chromoly Pins, Clips, (Perfect Skirt Coating and Offset Wrist Pin), Connecting Rods - IAG-Spec H-Beam Rods with ARP2000 rod bolts, Rod / Main Bearings - ACL or King Race Bearings, Crankshaft - Standard New Subaru Nitride Treated 2017+ STI Crankshaft, Case / Main Bolts - Standard FHI Subaru case bolt.
- Compression Ratio: 9.3:1 on D Cylinder Heads (EJ255) w/ OEM Head Gasket, 8.8:1 on B, V, and W EJ257 Heads w/ OEM Head Gasket, 9.4:1 on S20 Cylinder Heads without Combustion Mod and with OEM Head Gasket, 9.0:1 on D Cylinder Heads (EJ255) w/ .039" JE Proseal Head Gasket, 8.5:1 on B, V, and W EJ257 Heads w/ .039" JE Proseal Head Gasket, 9.1:1 on S20 Cylinder Heads without Combustion Mod and with .039" JE Proseal Head Gasket.
Additional Attributes:
Extended Information:
- Emissions : EPA Eligible
- Life Cycle Status: Available To Order
Packaging:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 21 x 17 x 21 inches
